2008 CATERPILLAR CP563E(BWE) - COMPACTORS
2008 CATERPILLAR CP563E(BWE) - COMPACTORS
or
Call +1 (956) 465-1981
Specifications
| Manufacturer | CATERPILLAR |
| Model | CP563E(BWE) |
| Year | 2008 |
| Condition | Used |
| Stock Number | 1049 |
| Status date | 10/1/2013 |
| Availabilty Status | Available |
| ENGINE MAKE | CAT 3056E ATAAC |
| ENGINE HP | 143.5 |
| TRANSMISSION | HY |
| STAT OR VIB | V |
| DRUM TYPE | SM-AND -SHELL PADFOOD |
| WEIGHT | 25479 |
| FUEL CAPACITY | 87.2 gal 330 L |
| COOLING SYSTEM FLUID CAPACITY | 6.9 gal 26 L |
| ENGINE OIL CAPACITY | 3.2 gal 12 L |
| HYDRAUILC SYSTEM FLUID CAPACITY | 16.9 gal 64 L |
| MAX SPEED | 7.2 mph 11.6 km/h |
| TIRES | Very Good |
| OPERATING VOLTAGE | 24 V |
| DRUM DIAMETER | 51 in 1295 mm |
| VIBRATION FREQUENCY (HIGH AMPLITUDE) | 0.07 in IN 31.9 Hz |
| VIBRATION FREQUENCY (LOW AMPLITUDE) | 0.03 in in IN 31.9 Hz |
| CENTRIFUGAL FORCE (HIGH AMPLITUDE) | 59799.2 lb 266 kN |
| CENTRIFUGAL FORCE (LOW AMPLITUDE) | 29899.6 lb 133 kN |
| NUMBER OF PADS | 140 |
| DRUM WIDTH | 84 in 2134 mm |
| PAD HEIGHT | 26.8 in 680 mm |
| PAD SURFACE AREA | 13.9 in2 8940 mm2 |
| APPEARANCE | Very Good |
| BLADE PINS Very Good | GENERAL CONDITION Very Good |
| BLADE PINS | Very Good |
| GENERAL CONDITION | Very Good |
| VIBRATORY SYSTEM Very Good | CAB Very Good |
| VIBRATORY SYSTEM | Very Good |
| CAB | Very Good |
| GLASS Good | AIR CONDITIONING Very Good |
| GLASS | Good |
| AIR CONDITIONING | Very Good |
| ALTERNATOR Very Good | DRUMS Very Good |
| ALTERNATOR | Very Good |
| DRUMS | Very Good |
| HEATER / DEFROSTER Very Good | ARTICULATION Very Good |
| HEATER / DEFROSTER | Very Good |
| ARTICULATION | Very Good |
| FEET Very Good | PADFOOT DRUM Very Good |
| FEET | Very Good |
| PADFOOT DRUM | Very Good |
| CYLINDERS Very Good | PUMPS Very Good |
| CYLINDERS | Very Good |
| PUMPS | Very Good |
| DRUM DRIVE Very Good | HYDRAULIC Very Good |
| DRUM DRIVE | Very Good |
| HYDRAULIC | Very Good |
| ENGINE Very Good | HYDRAULIC PUMP Very Good |
| ENGINE | Very Good |
| HYDRAULIC PUMP | Very Good |
| BRAKES Very Good | FINAL DRIVE LEFT Very Good |
| BRAKES | Very Good |
| FINAL DRIVE LEFT | Very Good |
| DIFFERENTIAL Very Good | FINAL DRIVE RIGHT Very Good |
| DIFFERENTIAL | Very Good |
| FINAL DRIVE RIGHT | Very Good |
| TIRE SIZE Very Good | TIRES Very Good |
| TIRE SIZE | Very Good |
| Overall width | 7.6 ft in 2316.5 mm |
| Wheelbase | 9.5 ft in 2900 mm |
| Ground clearance | 18 in 456 mm |
| Height to top of cab | 10.1 ft in 3070 mm |
| Width over tires | 7.6 ft in 2316.5 mm |
| Length with blade | 20.7 ft in 6300 mm |
| Length without blade | 18.9 ft in 5760 mm |
